FRAME
28", Super lite AL-6061 tubing, BES III, PowerTube battery
FORK
Suntour Mobie 25, RLR DS, 100 mm, 15x100 mm axle
DRIVE UNIT
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
BATTERY
Bosch PowerTube, 36 V Li Ion, 750 Wh
DISPLAY
Bosch LED Remote
REAR DERAILLEUR
Shimano Deore Linkglide, RD-M5130, Shadow Plus
SHIFTERS
Shimano Deore Linkglide, SL-M5130, 1x10-speed, rapidfire plus-shifter
CRANKSET
FSA CK-320, 38t
BB-SET
Bosch, Isis
CHAIN
Shimano CN-LG500
CASSETTE
Shimano CS-LG600-10, 11-43t
BRAKE LEVERS
Shimano BL-MT402, hydraulic disc brake
BRAKES
Shimano BR-MT420, hydraulic disc brake, 4-piston
ROTOR
Shimano SM-RT54, 180 mm
HANDLEBAR
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm
H'STEM
Satori Python, adjustable
SEATPOST
BGM Pro
SEAT
Syncros Capilano Urban, gel
HEADSET
Acros, A-Headset, semi-integrated, 1.5", with integrated cable routing
HUB (FRONT)
Shimano HB-MT400, centerlock, disc, 15x100 mm axle
HUB (REAR)
Shimano, centerlock, disc, quick release
SPOKES
Sapim Leader
RIMS
Ryde Rival 23 disc, eyelets
FRONT TIRE
Schwalbe Marathon Plus MTB, Smart Guard, Twin Skin, reflective stripe, 54-622 Tube: Schwalbe AV19
REAR TIRE
Schwalbe Marathon Plus MTB, Smart Guard, Twin Skin, reflective stripe, 54-622 Tube: Schwalbe AV19
LIGHTS
Front: B&M Myc, 50 Lux, LED Rear: B&M Toplight Line brex, LED, with brakelight
RACK & FENDERS
Fender: Racktime Wingee Carrier: Racktime / BGM Trekking Pro, Snapit 2.0 System, integrated fender mount
PEDALS
Marwi SP-890 Sandblock
ACCESSORIES
Kickstand: Syncros
APPROX WEIGHTS IN KG
28,9
COLOR
chrome silver (matt)
FRAME SIZE
44/48/52/56 cm
CHAIN COVER
Integrated in motor cover
GRIPS
BGM Comfort, Ergo, double density, clamp version
MAX. SYSTEM WEIGHT
160,0 kg
